Chapter 105 Disc Brakes
Quiz by Matt Lobdell
Feel free to use or edit a copy
includes Teacher and Student dashboards
Measure skillsfrom any curriculum
Tag the questions with any skills you have. Your dashboard will track each student's mastery of each skill.
- edit the questions
- save a copy for later
- start a class game
- automatically assign follow-up activities based on students’ scores
- assign as homework
- share a link with colleagues
- print as a bubble sheet
- Q1
What part causes the disc brake caliper piston to retract when the brakes are released?
The caliper bushings
The rotating rotor (disc) that pushes the piston back
Return (retracting) spring
The square cut O-ring
30s - Q2
Slots are often used in brake pads because they ________.
improve braking performance
reduce brake fade
reduce brake fade
increase brake life
30s - Q3
Which of the following is NOT a component of a disc brake system?
Caliper
Backing plate
Brake pads
Splash shield
30s - Q4
Technician A says that riveted disc brake pads are often quieter that bonded disc brake pads. Technician B says that integrally molded disc brake pads are molded into holes in the steel backing of the pads. Which technician is correct?
Technician A only
Technician B only
Both technicians
Neither technician
30s - Q5
Two technicians are discussing the reason that the brake fluid level in the master cylinder drops. Technician A says that it may be normal due to the wear of the disc brake pads. Technician B says that this is part of the wear compensation feature of disc brakes. Which technician iscorrect?
Technician A only
Technician B only
Both technicians
Neither technician
30s - Q6
Two technicians are discussing a floating-type disc brake caliper. Technician A says that if the caliper slides are corroded, one pad may wear more than the other pad on the same wheel brake. Technician B says that if a caliper slide is corroded, reduced braking may occur. Which technician is correct?
Technician A only
Technician B only
Both technicians
Neither technician
30s - Q7
Technician A says that disc brakes are self adjusting and the brake pedal height should not become lower as the disc brake pads wear. Technician B says that as the disc brake pads wear, the level of brake fluid in the master cylinder reservoir drops. Which technician iscorrect?
Technician A only
Technician B only
Both technicians
Neither technician
30s - Q8
Which type of disc brake caliper may leak fluid more often?
Fixed
Floating
Single piston
Sliding
30s - Q9
Technician A says that all vehicles equipped with rear disc brakes use a parking brake that is integrated in the caliper. Technician B says that all vehicles equipped with rear disc brakes use a small drum brake inside the rear rotor for a parking brake. Which technician is correct?
Technician A only
Technician B only
Both technicians
Neither technician
30s - Q10
A four piston caliper is used in what type of caliper design?
Floating
Fixed
Either fixed or floating
Sliding
30s - Q11
A quick take-up master cylinder is required when what type of caliper design is used on a vehicle?
Sliding
Low-drag
Two-piston
Fixed
30s - Q12
Technician A says that brake fade due to lining or water is not possible on disc brakes. Technician B says that lining and water fade can occur on disc brakes, but is not as likely compared to drum brakes.Which technician is correct?
Technician A only
Technician B only
Both technicians
Neither technician
30s - Q13
Technician A says that one disadvantage of disc brakes is noise. Technician B says that disc brakes have more holding power as a parking brake compared to drum brakes. Which technician is correct?
Technician A only
Technician B only
Both technicians
Neither technician
30s - Q14
When the pressure in a caliper is released, the piston is moved back in the cylinder by ________.
the leverage of the caliper arms
the opening of the vent port
spring pressure
the action of the piston seal
30s - Q15
Disc brakes have many advantages, some of which are listed below. Which of the following statements does NOT apply to disc brakes?
They are self-cleaning.
They dissipate heat faster.
They resist fading.
They are self-energizing.
30s
