Chapter 12 Measuring Systems and Tools
Quiz by Matt Lobdell
Feel free to use or edit a copy
includes Teacher and Student dashboards
Measure skillsfrom any curriculum
Tag the questions with any skills you have. Your dashboard will track each student's mastery of each skill.
- edit the questions
- save a copy for later
- start a class game
- automatically assign follow-up activities based on students’ scores
- assign as homework
- share a link with colleagues
- print as a bubble sheet
- Q1
The threaded movable part that rotates on a micrometer is called the ________.
spindle
anvil
barrel
thimble
30s - Q2
To check a crankshaft journal for taper, the journal should be measured in at least how many locations?
1
2
4
6
30s - Q3
To check a crankshaft journal forout-of-round, the journal should be measured in at least how many locations?
2
4
6
8
30s - Q4
A telescopic gauge can be used to measure a cylinder bore if what other measuring device is used to measure the telescopic gauge?
Feeler gauge
Dial indicator
Small hole gauge
Micrometer
30s - Q5
To directly measure the diameter of a valve guide in a cylinder head, use a micrometer and a ________.
dial indicator
telescopic gauge
feeler gauge
small hole gauge
30s - Q6
Which of the following CANNOT be measured using a feeler gauge?
Piston ring side clearance
Piston ring gap
Connecting rod side clearance
Valve guide clearance
30s - Q7
Which of the following CANNOT be measured using a straightedge and a feeler gauge?
Cylinder head flatness
Straightness of the main bearing bores
Straightness of the cylinder bore
Block deck flatness
30s - Q8
Which measuring gauge needs to be set up(adjusted) to a fixed dimension before use?
Dial bore gauge
Micrometer
Dial indicator
Dial caliper
30s - Q9
The freezing point of water is ________.
32° F
0° C
0° F
Both A and B
30s - Q10
Which metric unit of measure is used for volume measurement?
Cubic centimeter (cc)
Centimeter
Millimeter
Meter
30s - Q11
Which of these objects have a mass of approximately one gram?
Birds feather
Small paper clip
Large bolt
None of these
30s - Q12
There are ________ millimeters in one centimeter.
0.10
1000
100
10
30s - Q13
Micrometers are calibrated using a________.
gauge rod
metric ruler
Both A and B
Neither A nor B
30s - Q14
For measuring a journal for out-of-round, measurements should be taken every ________ around the journal
180°
90°
260°
120°
30s - Q15
On pushrod engines, camshaft journal diameter often ________ toward the rear of the engine.
increases
decreases
Both A and B
Neither A nor B
30s
