- Q 1/50Score 0
The displayed image is an example of which type of generic switch contact designation?
29Normally-open
Never-open
Never-closed
Normally-closed
- Q1
The displayed image is an example of which type of generic switch contact designation?
Normally-open
Never-open
Never-closed
Normally-closed
60s - Q2
The displayed image is an example of which type of generic switch contact designation?
Normally-closed
Never-open
Never-closed
Normally-open
60s - Q3
A spike in current when starting a circuit is known as?
outrush current
rushing current
influx current
inrush current
60s - Q4
Full Load Amps, or F.L.A., represents the amount of current a motor will draw at its rated horsepower.
truefalseTrue or False60s - Q5
Electrical wire color codes are color-coded for safety. Match each color wire with the correct response.
Users link answersLinking120s - Q6
Match each size wire with the correct color of the insulated outer jacket.
Users link answersLinking120s - Q7
Match Each Unit with its respective standard unit of measurement.
Users link answersLinking120s - Q8
Match each wire insulation jacket color with the correct amperage it is used for.
Users link answersLinking120s - Q9
Match each wire size to its correct amperage.
Users link answersLinking120s - Q10
Match each common color screw with the correct wire for household switches and receptacles.
Users link answersLinking120s - Q11
Which type of outlet must be installed in bathrooms, garages, crawl spaces, basements, laundry rooms and areas where a water source is present.
Ungrounded
GFCI
USB
Smart
120s - Q12
On an outlet the (Long Slot) correlates with which part of the circuit?
Ground
Neutral
None of the above
Hot
120s - Q13
On an outlet the (Short Slot) correlates with which part of the circuit?
Neutral
Hot
Ground
None of the above
120s - Q14
On an outlet the (Rounded Slot) correlates with which part of the circuit?
Ground
Hot
None of the above
Neutral
120s - Q15
On an outlet the Silver Terminal is for which color wire?
Green or Bare (Copper)
None of the above
White
Black or Red
120s
