Chapter 106 Disc Brake Diagnosis and Service

A vehicle is in for a brake inspection and the red brake warning light is ON. Which of the following actions should the technician NOT take?

Uneven disc brake pad wear is being discussed. Technician A says the caliper piston may be stuck. Technician B says the caliper may be stuck on the slides and unable to "float." Which technician is correct?

A "chirping" noise is heard while the vehicle is moving forward, but stops when the brakes are applied. Technician A says that the noise is likely caused by the disc brake pad wear sensors. Technician B says the noise is likely a wheel bearing because the noise stops when the brakes are applied. Which technician is correct?

Technician A says that disc brake pads should be replaced when worn to minimal allowable thickness. Technician B says the pads should be removed and inspected whenever there is a brake performance complaint. Which technician is correct?

Two technicians are discussing ways of removing a caliper piston. Technician A says to use compressed air. Technician B says to use large pliers. Which technician is correct?

Technician A says that a loaded caliper includes an overhauled caliper assembly but no brake pads or hardware. Technician B says that a loaded caliper includes the pads and all needed hardware. Which technician is correct?

Technician A says that a steel piston should be cleaned with sandpaper to remove rust. Technician B says that brake assembly fluid or clean brake fluid should be used to lubricate the caliper pistons before installing in the caliper. Which technician is correct?

Technician A says that a lack of lubrication on the back of the disc brake pads can cause brake noise. Technician B says that pads that are not correctly crimped to the caliper housing can cause brake noise. Which technician is correct?

What should be done after installing new disc brake pads?

Which of the following lubricants should be used to lubricate moving or sliding disc brake components?

A typical disc brake caliper overhaul (OH) kit usually includes what parts?

Which is NOT a recommended type of grease to use on brake parts?

Technician A says that all metal-to-metal contact areas of the disc brake system should be lubricated with special brake grease for proper operation. Technician B says that the lubrication helps reduce brake noise (squeal). Which technician is correct?

After a disc brake pad replacement, the brake pedal went to the floor the first time the brake pedal was depressed. The most likely cause was ________.

What is not included with a loaded caliper?
