Chapter 109 Power Brake Unit Operation, Diagnosis, and Service

Quiz by Matt Lobdell

Our brand new solo games combine with your quiz, on the same screen

Correct quiz answers unlock more play!

New Quizalize solo game modes
24 questions
Show answers
  • Q1

    A power brake booster provides which of the followingdesign features?

    Reduced stopping distance

    High brake pedal effort

    Reduced pedal effort

    A lower brake pedal position

    30s
  • Q2

    The proper operation of a vacuum brake booster requires that the engine be capable of supplying at least ________.

    21 in. Hg vacuum

    15 in. Hg vacuum

    17 in. Hg vacuum

    19 in. Hg vacuum

    30s
  • Q3

    A defective vacuum brake booster will cause a________.

    hard brake pedal

    low brake pedal

    soft (spongy) brake pedal

    slight hiss noise when the brake pedal is depressed

    30s
  • Q4

    A brake pedal feels spongy when depressed. Technician A says that a defective hydraulic brake booster could be the cause. Technician B says that a defective vacuum brake booster could be the cause. Which technician is correct?

     Technician A only

     Technician B only

    Both technicians

    Neither technician

    30s
  • Q5

    Two technicians are discussing vacuum brake boosters. Technician A says that a low, soft brake pedal is an indication of a defective booster. Technician B says that there should be at least two power-assisted brake applications after the engine stops running. Which technician is correct?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q6

    Technician A says that to check the operation of a vacuum brake booster, the brake pedal should be depressed until the assist is depleted and then start the engine. Technician B says that the brake pedal should drop when the engine starts, if the booster is okay. Which technician iscorrect?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q7

    Which of these could be caused by an improperly adjusted booster pushrod?

    A soft pedal

    Brakes to overheat

    A low pedal

    None of these

    30s
  • Q8

    An accumulator, such as that used on hydraulic brake boosters________.

    provides higher force being fed back to the driver'sfoot

    provides a reserve in the event of a failure

    reduces brake pedal noise

    works against engine vacuum

    30s
  • Q9

    The first step in diagnosing a Hydro-Boost problem is________.

    a thorough visual inspection

    to tighten the power steering drive belt

    a pressure test of the pump

    a volume test of the pump

    30s
  • Q10

    If the engine stops running, what is the most likely to occur if the vehicle is equipped with a Hydro-Boost power brake system?

    A low and spongy brake pedal

    A high and hard brake pedal

    Greatly reduced braking distance but a normal feeling brake pedal

    Normal braking using the accumulator pressure

    30s
  • Q11

    Two technicians are discussing vacuum brake boosters. Technician A says that when the engine is running and the driver's foot is off the brake pedal, a vacuum is present on both sides of the booster diaphragm. Technician B says that when the brakes are in the applied position, vacuum is present on the front side of the diaphragm. Which technician is correct?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q12

    To provide the driver with a sense of "feel"during braking, vacuum boosters use a ________.

    return spring

    pressure restrictor

    diaphragm spacer

    vacuum diverter

    30s
  • Q13

    A hydraulically operated booster unit stores fluid under pressure by means of a(n) ________.

    accumulator

    actuator

    pressure chamber

    boost piston

    30s
  • Q14

    A common source of vacuum for boosters used on diesel engines is ________.

    exhaust manifold

    carburetor

    auxiliary vacuum pump

    intake manifold

    30s
  • Q15

    Technician A says when the brakes are applied in a vacuum booster, the vacuum control valve is closed. Technician B says the vacuum control valve is opened. Which technician is correct?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
