Crosscheck #3 Road Type (3rd day)
Quiz by Mark Lester Diacos
Tag the questions with any skills you have. Your dashboard will track each student's mastery of each skill.
Which of the following RART types represents a Separated Multi-lane Road with the following characteristics?
Separation from oncoming: Physical / No oncoming lane
Number of lanes: 2 or more
Separation from same direction: Painted
Separation from road edge: Physical or Painted
Junctions: Soft merges and splits only
Minimum length: 3 km
Which of the following RART types represents a Separated, well-painted, multi-lane road with the following characteristics?
Separation from oncoming: Physical / No oncoming lane
Number of lanes: 2 or more
Separation from same direction: Painted
Separation from road edge: Physical or Painted
Junctions: Allowed
Auxiliary rule: If an RART 0 section is less than 3 km.
Which RART type represents a single-lane road with the following characteristics?
Separation from oncoming: Physical / No oncoming lane
Number of lanes: 1
Separation from same direction: None
Separation from road edge: Physical or Painted
RART 2 applies when there is only one lane with a physical separator, no separation within the same direction, and the separation from the road edge may be either physical or painted. If there is no oncoming lane, we assume a physical separator.
Which RART type represents a non-physically separated, well-painted, multi-lane road with the following characteristics?
Separation from oncoming: Painted
Number of lanes: 2 or more
Separation from same direction: Painted
Separation from road edge: Physical or Painted
Junctions: Yes
Which RART type represents a single-lane road with the following characteristics?
Separation from oncoming: Painted
Number of lanes: 1
Separation from same direction: None
Separation from road edge: Physical or Painted
Which RART type represents a non-physically separated, multi-lane road with the following characteristics?
Separation from oncoming: Painted
Number of lanes: 2 or more
Separation from same direction: Painted
Separation from road edge: None (No RE)
Junctions: Allowed
Which RART type represents a single-lane road without a road edge (RE) and has the following characteristics?
Separation from oncoming: Painted
Number of lanes: 1
Separation from same direction: None
Separation from road edge: No RE
Which RART type represents a separated multi-lane road without painted lane markings in the same direction, but with a defined road edge (RE), and has the following characteristics?
Separation from oncoming: Physical / No oncoming lane
Number of lanes: 2 or more
Separation from same direction: None
Separation from road edge: Physical or Painted
Which RART type represents a separated multi-lane road without painted same-direction lane markings and without a road edge (RE), having the following characteristics?
Separation from oncoming: Physical / No oncoming lane
Number of lanes: 2 or more
Separation from same direction: None
Separation from road edge: No RE
RART 8 has a physical separator from oncoming traffic and two or more lanes per direction. It has no separation between lanes in the same direction and no road edge or painted border. If there is no oncoming lane, we assume a physical separator is present.
Which RART type represents a non-physically separated, multi-lane road with no painted lane markings between lanes in the same direction, and with a defined road edge (RE)?
Separation from oncoming: Painted
Number of lanes: 2 or more
Separation from same direction: None
Separation from road edge: Physical or Painted
Which RART type represents a non-physically separated, multi-lane road with no painted same-direction lane markings and without a road edge (RE)?
Separation from oncoming: Painted
Number of lanes: 2 or more
Separation from same direction: None
Separation from road edge: No RE
Which RART type represents a non-separated road section with lane markings located next to the road edge (RE)?
Separation from oncoming: None
Number of lanes: Unlimited
Separation from same direction: Not applicable (N/A)
Separation from road edge: Physical or Painted
Which RART type represents a non-separated road with no lane markings (LM) and no road edge (RE)?
Separation from oncoming: None
Number of lanes: Not applicable (N/A)
Separation from same direction: Not applicable (N/A)
Separation from road edge: No RE
Which RART type serves as a placeholder for “Unknown” cases, typically used for parking areas, private properties, or establishments, and is only tagged if the case has a DP?
Represents the “Unknown” category
Usually applied to parking areas, private properties, or establishments
Only tagged if the case has a DP
