Chapter 107 Parking Brake Operation, Diagnosis, and service

Quiz by Matt Lobdell

Our brand new solo games combine with your quiz, on the same screen

Correct quiz answers unlock more play!

New Quizalize solo game modes
24 questions
Show answers
  • Q1

    Technician A says that the parking brake hand lever can turn on the red brake warning lamp. Technician B says that a foot-operated parking brake can turn on the red brake warning lamp. Which technician iscorrect?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q2

    Technician A says that if the parking brake cable is adjusted too tight, the rear brakes may drag and overheat. Technician B says that the parking brake is adjusted properly if the cable is tight when in the released position. Which technician is correct?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q3

    On most drum brake systems, the ________ attaches to the parking brake lever or handle inside the vehicle

    application cables

    control cables

    foot pedal

    transfer cables

    30s
  • Q4

    In a typical integral rear disc brake caliper, the parking brake cable moves the ________.

    auxiliary piston

    rotor

    caliper

    actuator screw

    30s
  • Q5

    On most vehicles, the ________ transmits the force passed through the linkage to apply the rear brakes.

    transfer cables

    application cables

    control cables

    foot pedal

    30s
  • Q6

    The rear brakes should be inspected, and adjusted if necessary, if the parking brake requires more than ________.

    15 clicks

    5 clicks

    20 clicks

    10 clicks

    30s
  • Q7

    Technician A says that the parking brake cable should be adjusted at each wheel. Technician B says that the parking brake cable adjustment is usually done after adjusting the rear brakes. Which technician iscorrect?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q8

    A rear drum brake is being inspected. The primary shoe is not contacting the anchor pin at the top. Technician A says that this is normal. Technician B says that the parking brake cable may be adjusted too tight or is stuck. Which technician is correct?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q9

    Technician A says that a hose clamp can be used to compress the retainer fingers of a parking brake cable in order to remove it from the backing plate. Technician B says a box-end wrench can be used instead of a hose clamp. Which technician is correct?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q10

    Technician A says that an electric parking brake (EPB) uses an electric motor to pull on the parking brake cable. Technician B says that some electric parking brake systems use a computer controlled motor attached to the caliper. Which technician is correct?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q11

    Technician A says that the parking brake cable adjustment should be performed before adjusting the rear brakes. Technician B says that the parking brake cable should allow for about 15 "clicks" before the parking brake holds. Which technician is correct?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q12

    Excess slack in the parking brake cables can be eliminated in most cases by an adjustment at the ________.

    operating lever

    link

    equalizer

    star wheel adjusters

    30s
  • Q13

    Two technicians are discussing parking brake systems that mechanically actuate the rear disc brakes. Technician A says that the calipers are self-adjusting. Technician B says that the actuating cables are adjustable at the equalizer. Which technician is correct?

    Technician A only

    Technician B only

    Both technicians

    Neither technician

    30s
  • Q14

    The parking brake warning light is independent of all other systems.

    false
    true
    True or False
    30s
  • Q15

    Federal regulations require the parking brake to hold the vehicle in position on a 20 percent grade.

    true
    false
    True or False
    30s
